Advance Universal Gearbox Series

The company’s industrial transmission products cover various fields such as building materials, metallurgy, food processing, petrochemical, electric power, mining, coal, transportation, rubber and plastic, lifting, test stand, railway engineering, marine engineering, new energy and so on. We can develop all kinds of industrial gearboxes, general-purpose gearboxes, high-speed gearboxes, non-standard customized gearboxes and system assemblies, etc. Our design and manufacturing capabilities are at the leading level in China.

Advantages Of  Advance Universal Gearbox Series

1. Gearbox novel structure, so that its use becomes very reliable. The excellent design makes the gearbox and engine arrangement more soft and smooth.
2. Small in size, clear in weight. The ease of use and maintenance is fully considered in the design.

3. With excellent machine performance, good design effectively reduce the noise, reduce the vibration.

4. European standard manufacturing, making the structure strong and durable, smooth work.

5. Excellent deceleration effect and bearing propeller thrust.

6. Professional gearbox specialists and after-sales service, spare parts directly available from stock.

Advance Universal Gearbox Series

This is a list of all of Advance Universal Gearbox Series.
Click here to find Advance universal gearbox series by type.

Advance HCF2300 Transfer Case

Advance HCF2300 Transfer Case

Model : HCF2300
Engine Rated Power : 350 kW
Engine Maximum Speed : 3450 r / min
Maximum Input Torque : 23000 N · m
Gear Ratio : 1
Torque – splitting Ratio : 1 : 1

Advance HCF1580 Transfer Case

Advance HCF1580 Transfer Case

Model : HCF1580
Engine Rated Power : 390 kW
Engine Maximum Speed : 3450 r / min
Maximum Input Torque : 15800 N · m
Gear Ratios : 1.32 / 0.9
Torque – splitting Ratio : 1 : 2

Advance YJ450 Torque Converter

Advance YJ450 Torque Converter

Model : YJ450
Effective Diameter : 450 mm
Torque Converter Coefficient (Zero-Speed) : 2.13
Nominal Torque (Zero-Speed) : 715 N·m
Max Efficiency : 0.82
Output : Flanged, single

Advance YJ407 Hydraulic Torque Converter

Advance YJ407 Hydraulic Torque Converter

Model : YJ407
Effective Diameter : 407 mm
Torque Converter Coefficient (Zero – Speed) : 1.89
Nominal Torque (Zero – Speed) : 450.5 N·m
Max Efficiency : 0.84
Output : Flanged, single

Advance YJ315X Torque Converter

Advance YJ315X Torque Converter

Model : YJ315X
Effective Diameter : 315 mm
Torque Converter Coefficient (Zero-Speed) : 2.86
Nominal Torque (Zero-Speed) : 68.27 N·m
Max Efficiency : 0.812
Output : Flanged, single (with 3 PTO ports)

Advance YJ305 Hydraulic Torque Converter

Advance YJ305 Hydraulic Torque Converter

Model : YJ305
Effective Diameter : 305 mm
Torque Converter Coefficient (Zero-Speed) : 2.31
Nominal Torque (Zero-Speed) : 100 N·m
Max Efficiency : 0.86
Output : Flanged, single

Advance YJ280 Torque Converter

Advance YJ280 Torque Converter

Model : YJ280
Effective Diameter : 280 mm
Torque Converter Coefficient (Zero-Speed) : 3.12
Nominal Torque (Zero-Speed) : 39 N · m
Max Efficiency : 0.836
Output : Flanged, single

Advance EBJ235 Electric – Drive Box

Advance EBJ235 Electric – Drive Box

Model : EBJ235
Travel Motor Rated Power : 125 kW
Travel Motor Peak Torque : 1090 N·m
Travel Motor Peak Speed : 7500 rpm
Hydraulic Motor Rated Power : 106 kW
Hydraulic Motor Peak Torque : 312 N·m

Advance EXB168 / EXB178 Electric – Drive Box

Advance EXB168 / EXB178 Electric – Drive Box

Model : EXB168 / EXB178
Travel Motor Rated Power : 120 kW
Travel Motor Peak Torque : 1200 N·m
Travel Motor Peak Speed : 6000 rpm
Hydraulic Motor Rated Power : 60 kW
Hydraulic Motor Peak Torque : 350 N·m

Advance EDB240 Electric – Drive Box

Advance EDB240 Electric – Drive Box

Model : EDB240
Travel Motor Rated Power : 160 kW
Travel Motor Peak Torque : 1100 N·m
Travel Motor Peak Speed : 8000 rpm
Hydraulic Motor Rated Power : 100 kW
Hydraulic Motor Peak Torque : 320 N·m

Advance XB100 Hydraulic Gearbox

Advance XB100 Hydraulic Gearbox

Model : XB100
Max. power : 110 kW
Max. input speed : 3500 r / min
Max. input torque : 770 N · m
Center distance : 185 mm
Input type : Hydraulic motor

Advance 2JY160 Hydrostatic Transmission

Advance 2JY160 Hydrostatic Transmission

Model : 2JY160
Small Motor Max. speed : 5000 r / min
Small Motor Max. input : 1200 N · m torque
Large Motor Max. input : 1600 N · m torque
Large Motor Max. speed : 5000 r / min
Output type : Flange

Advance YDH130A Hydraulic Gearbox

Advance YDH130A Hydraulic Gearbox

Model : YDH130A / YDH130
Max. power : 130 kW
Max. speed : 2500 r / min
Max. input : 1000 N · m torque
Output type : Flange, Dual output

Advance YDH85 Hydraulic Gearbox

Advance YDH85 Hydraulic Gearbox

Model : YDH85
Max. power : 85 kW
Max. speed : 2500 r / min
Max. input : 650 N · m torque
Output type : Flange, Dual output

Advance YB360 Hydraulic Gearbox

Advance YB360 Hydraulic Gearbox

Model : YB360
Max. power : 360 kW
Max. speed : 2500 r / min
Max. input : 3600 N · m torque
Output type : Flange, Dual output

Advance YH350 Hydraulic Gearbox

Advance YH350 Hydraulic Gearbox

Model : YH350
Max. power : 350 kW
Max. speed : 2300 r / min
Max. input : 3000 N · m torque
Output type : Flange, Dual output

Advance YB310 Hydraulic Gearbox

Advance YB310 Hydraulic Gearbox

Model : YB310
Max. power : 310 kW
Max. speed : 2500 r / min
Max. input : 2950 N · m torque
Output type : Flange, Dual output

Advance AYB300 Hydraulic Gearbox

Advance AYB300 Hydraulic Gearbox

Model : AYB300
Max. power : 300 kW
Max. speed : 2100 r / min
Max. input : 2900 N · m torque
Output type : Flange, Single output

Advance YB260 Hydraulic Gearbox

Advance YB260 Hydraulic Gearbox

Model : YB260
Max. power : 260 kW
Max. speed : 2500 r / min
Max. input : 1650 N · m torque
Output type : Flange, Dual output

Advance YB250 Hydraulic Gearbox

Advance YB250 Hydraulic Gearbox

Model : YB250
Max. power : 230 kW
Max. speed : 2200 r / min
Max. input : 2450 N · m torque
Output type : Flange, Dual output

Advance YB230 Hydraulic Gearbox

Advance YB230 Hydraulic Gearbox

Model : YB230
Max. power : 230 kW
Max. speed : 2500 r / min
Max. input : 1650 N · m torque
Output type : Flange, Dual output

Advance YB171 Hydraulic Gearbox

Advance YB171 Hydraulic Gearbox

Model : YB171
Max. power : 170 kW
Max. speed : 2600 r / min
Max. input : 1350 N · m torque
Output type : Flange, Dual output

Advance YB160 Hydraulic Gearbox

Advance YB160 Hydraulic Gearbox

Model : YB160
Max. power : 160 kW
Max. speed : 2500 r / min
Max. input : 1100 N · m torque
Output type : Flange, Dual output

Advance YB85 Hydraulic Gearbox

Advance YB85 Hydraulic Gearbox

Model : AYB85
Max. power : 82 kW
Max. speed : 2200 r / min
Max. input : 750 N · m torque
Output type : Flange, Dual output

Advance YB82 Hydraulic Gearbox

Advance YB82 Hydraulic Gearbox

Model : YB82
Max. power : 82 kW
Max. speed : 2200 r / min
Max. input : 680 N · m torque
Output type : Flange, Dual output

Advance ZL50D Hydraulic Gearbox

Advance ZL50D Hydraulic Gearbox

Model : ZL50D
Max. power : 154 kW
Max. speed : 2200 r / min
Max. input : 2500 N · m torque
Output type : Flange, Dual output

Advance DB428 Hydraulic Gearbox

Advance DB428 Hydraulic Gearbox

Model : DB428
Max. power : 130 kW
Max. speed : 2600 r / min
Max. input : 1000 N · m torque
Output type : Flange, Dual output

Advance BS428 Hydraulic Gearbox

Advance BS428 Hydraulic Gearbox

Model : BS428
Max. power : 74 kW
Max. speed : 2500 r / min
Max. input : 650 N · m torque
Output type : Flange, Dual output

Advance DB55 Hydraulic Gearbox

Advance DB55 Hydraulic Gearbox

Model : DB55
Max. power : 58 kW
Max. speed : 2400 r / min
Max. input : 670 N · m torque
Output type : Flange, Dual output

Advance YD131 Hydraulic Gearbox

Advance YD131 Hydraulic Gearbox

Model : YD131
Max. power : 130 kW
Max. speed : 2600 r / min
Max. input : 1000 N · m torque
Output type : Flange, Dual output

Advance YD130 Hydraulic Gearbox

Advance YD130 Hydraulic Gearbox

Model : YD130
Max. power : 130 kW
Max. speed : 2600 r / min
Max. input : 1000 N · m torque
Output type : Flange, Dual output
